- Place of Origin: china
- Brand Name: hengxing
- Model Number: QT10-15
The machine imported the technology form foreign countries and combined with our home technology which have tightly structure,nice oufline,high durability,low error rate and fully auomatic.Imported parts form foreign countries e.g.computers,hydraulic pressure parts,airproof parts which are in common use and have high stability.
The machine is multifunctional which can produce air brick,heat insulator,grass,brick,etc...The machine has high accuracy in the size of the products and geometry product.
Technical parameter
Main Technical Specification: | |
Production | 10pcs/mould, 15,000pcs/8 hours(hollow block:400x200x200mm) |
54pcs/mould, 80,000pcs/8 hours(solid block:240x115x53mm) | |
27pcs/mould, 40,000pcs/8 hours(interlock:240x130x60mm) | |
35pcs/mould, 52,000pcs/8 hours(paving block:200x100x60mm) | |
Working cycle time | 18-25s |
Main machine dimension | 3300x2670x3150mm |
Main machine weight | 12T |
Main machine power | 42kw |
Vibration force | 90-100kn |
Pallet size | 1300x860x30mm |
Factory area | 1000 square meters |
