- Place of Origin: QUANZHOU,CHINA
- Brand Name: hengxing
- Model Number: HZS35 HZS50
- :
- :
- :
Concrete mixing plant, concrete mixing station, concrete mixing mahcine. concrete batching plant concrete mixer machine concrete mixing plant small concrete mixer machine HZS35 HZS50 Automatic concrete batching plant concrete mixing plant small concrete mixer machine ready mix concrete batch plant
HZS50 concrete batching plant for sale Ready mixed concrete plant is composed of mixer, materials weighting system, material conveyor system, control system and other subsidiary facilities. According to different collocate, Scope of appplication and efficacy concrete batching plant italy can be divided into road-mixed(HZS25/35/50/75/100/150) and ready-mixed (HZS60/90/120/180/200). Road-mixed also can divide into bucket HZSD, movable HZSY, modular HZS.
HZS50 concrete batching plant for sale Ready mixed concrete plant is designed and developed and based on introducing and digesting both home and abroad’s similar type products *advanced technical* advantages and using experience. concrete batching plant italy is widely used for architecture project transportation project, construction of municipal, water conservancy, airport construction, port construction Metallurgy Mining and construction building site of all series.
The feature of HZS35 HZS50 Automatic concrete batching plant concrete mixing plant small concrete mixer machine ready mix concrete batch plant technology:
1.Mixing system:
A.Horizontal twin shaft mixer or planetary mixer
B.Italian SICOMA mixer or JS mixer made by ourcompany.
C.Germany BHS, TEKA of mixer etc.
2.Control system:
A.Mitsubishi PLC, self diagnosed for trouble shooting
B.Industry computer control plus printer, daily report, monthly report, yearly report
C. International electrical components: Omron, Schnieider
D.Monitor system
3.Batching system
A. According to customer's site , it has under-ground batcher( concrete structure)
B. It has Accumulative weighing system and individual weighing system
HZS35 HZS50 Automatic concrete batching plant concrete mixing plant small concrete mixer machine ready mix concrete batch plant
Technical Parameter of main models:
Model | HZS50 | HZS90 | HZS120 | HZS180 | HZS200 | |
Productivity (m3/h) | 50 | 90 | 120 | 180 | 200 | |
Host machine of mixer |
Model | JS1000 | JS1500 | JS2000/ MAO3000 | JS3000/ MAO4500 | JS4000/ MAO6000 |
Mixer power(kw) | 2×22 | 2×30 | 2×37 | 2×55 | 2×75 | |
Output capacity(m3) | 1.0 | 1.5 | 2 | 3 | 4 | |
Aggregate Size (mm) | ≤60 | ≤80 | ≤120 | ≤150 | ≤150 | |
Capacity of Belt conveyor(t/h) | 200 | 200 | 300 | 400 | 600 | |
Weighting scope and precision | Aggregate(kg) | 2500 ×±2% | 3500±2% | 4500±2% | 6000±2% | 9000±2% |
Cement(kg) | 600±1% | 900±1% | 1200±1% | 1800±1% | 2400±1% | |
fly ash(kg) | 200±1% | 300±1% | 400±1% | 600±1% | 800±1% | |
Water(kg) | 300±1% | 400±1% | 600±1% | 800±1% | 1000±1% | |
Additives(kg)
| 10±1% | 30±1% | 30±1% | 50±1% | 50±1% | |
Total power (kw) | 80 | 123 | 145 | 198 | 220 | |
unloading height | 3.8 | 3.8 | 3.8 | 3.8 | 3.8 | |
