- Place of Origin: QUANZHOU, CHINA
- Brand Name: hengxing
- Model Number: HZS35 HZS60
- :
- :
- :
- :
- :
- :
HZS35 HZS60 Automatic Fixed Concrete mixing plant Mobile concrete batch plant Automatic concrete batching plant
Configuration:
1. Batcher(3 bins)
2. Protective Fencing
3. Hopper Hoist System
4. Main building and Guidance
5. Mixer
6. Weighing System
7. Screw Conveyor
8. Silo
HZS35 HZS60 Automatic Fixed Concrete mixing plant Mobile concrete batch plant Automatic concrete batching plant is composed of mixer, materials weighting system, material conveyor system, control system and other subsidiary facilities. According to different collocate, Scope of appplication and efficacy it can be divided into road-mixed(HZS25/35/50/75/100/150) and ready-mixed (HZS60/90/120/180/200). Road-mixed also can divide into bucket HZSD, movable HZSY, modular HZS.
HZS35 HZS60 Automatic Fixed Concrete mixing plant Mobile concrete batch plant Automatic concrete batching plant are new types of concrete mixing plants mixer designed by HXJX adopting the worldwide advanced technologies and research achievements during the 90’s with many years of experiences in production of concrete mixing plants. They are the most ideal plants in China as they are compact in design, mobile in site-transfer and easy in installation. They are suitable for various large construction sites such as roads, bridges, dams, airports, seaports and sites in great demand of concrete such as ready-mixed concrete production centers.
Company introduction of HZS35 HZS60 Automatic Fixed Concrete mixing plant Mobile concrete batch plant Automatic concrete batching plant HZS35 HZS60 Automatic Modular Concrete mixing plant Mobile concrete batch plant for sale Automatic concrete batching plant
Quanzhou Hengxing Industry Machinery Co., Ltd., is located in Dongmen Industrial Area, Fengzhou Town, Quanzhou CIty, Fujian Province, China. Hengxing Industry Machinery company is a manufacturer specializing in concrete block making machine series,cement concrete mixing plant series, stabilized soil mixing plant series, asphalt concrete mixing plant series and wall panel making machine. Our company has developed into a High-Tech Enterprise with intergration of R&D manufacture sale and service. Our products are well sold all around the world based on a professional quality constituted by leading technology and excellent workforce, sophisticated equipment, advanced techniques, first-class standard, strict management, perfect service system.
- Place of Origin: QUANZHOU, CHINA
- Brand Name: hengxing
- Model Number: HZS35 HZS60
- :
- :
- :
- :
- :
- :
Model | HZS35 | HZS60 | HZS75 | HZS120 | |
Productivity(m3/h) | 35 | 60 | 75 | 120 | |
Host machine of mixer | Model | JS750 | JS1000 | JS1500 | JS2000 |
Mixer power(kw) | 30.0 | 2×22 | 2×30 | 2×37 | |
Output capacity(m3) | 0.75 | 1 | 1.5 | 2 | |
Aggregate Size (mm) | ≤60 | ≤60 | ≤80 | ≤120 | |
Capacity of Belt conveyor(t/h) | 150 | 200 | 200 | 300 | |
Weighting scope and precision | Aggregate(kg) | 2500 ±2% | 2500±2% | 3500±2% | 4500±2% |
Cement(kg) | 400±1% | 600±1% | 900±1% | 1200±1% | |
Fly ash(kg) | × | 200±1% | 300±1% | 400±1% | |
Water(kg) | 200±1% | 300±1% | 400±1% | 600±1% | |
Additives(kg) | 15±1% | 10±1% | 30±1% | 30±1% | |
Total power (kw) | 65 | 98 | 108 | 145 | |
unloading height | 3.8 | 3.8 | 3.8 | 3.8 | |
