High Efficiency wall panel making machine lightweight automatic block making machine
Lightweight Automatic concrete art fence equipment for precast concrete is suitable for Lightweight wall panel,internal wall panel, external wall panel,concrete fence panel, EPS sandwich wall panel, solid wall panel and MGO wall panel of various materials. The thickness, length can be adjusted; the use of a machine (60, 90, 120, 150, 180) can be produced. This machinery can produce Hollow panel(KPB), Solid panel(SPB), Reinforced Panel(JPB) and Sandwich Panel(FPB), with advantage of flexible investment, one set of machinery can produce various panels, It is suitable for both small and large manufacturing on production.
Technology features
There is not any requirement about high temperature and high pressure during production processing. The board will be formed at one time after roller-extruding under the conditions of normal temperature and normal pressure. This is a green environmental-protection project, because that there is no waste water, waste materials and waste gas during its production processing. The finished board don’t need high temperature drying, air-drying and watering, and under the normal temperature, they will dry well indoor.
- Size: based on different part
- Place of Origin: Quanzhou, Fujian, China
- Brand Name: hengxing
- Model Number: wall panel making machine
- Weight: 27000.000 kg
wall panel making machine technical parameters:
Function | feeding capacity | wall panel size | productivity of diffreent thickness | hydraulic unit | moulding cycle | machine weight | composition | ||
moulding device | 1.7m3 | 2440×600 ×75/90/100 /150/200mm | 75mm | 12pcs | motor power | 2.2kw | 2hours (alumina cement) | 5t | host machine
hydraulic unit
moulds |
90mm | 10pcs | piston daimter | φ80mm | ||||||
100mm | 9pcs | working route | 400mm | ||||||
150mm | 7pcs | working press | 3-4Mpa | ||||||
200mm | 5pcs |
grouting container technical parameters:
function | grouting capaciy | working press | motor power | size | composition | |
transfer and press the material in the mixter inject into the moulding machine | 1m3 | 0.4Mpa | running motor: 1.1kw | air compressor motor: 3kw | 2755*1200* 1665mm | grouting machine running gear air compressor.pipeline |
Model | JQ1000 Light Weight Aggregate Compulsory Mixer | |
Performance | Type | Fixation |
Charging Volume | 1700L | |
Discharging Volume | 1000L | |
Capacity | 20-23m³ /h | |
Rotate Speed | 28r/min | |
Maximum Aggregate Diameter | 5mm | |
Water Weighing Accuracy | ≥ 2% | |
Discharging Height | 2000mm | |
Electromotor | Mixer | Y160L-6/11 |
Lift Pot | Y100-4 | |
Water Pump | 40ZBS-50-1.1 | |
Frame Dimension | 5800× 2900× 5200(Length× Width× Height) | |
Weight | 4700Kg |
