Automatic Brick Making Machine of Main Technical features (HQTY6-21)

1, Automatic Brick Making Machine of control system (Mitsubishi PLC):

A. Mitsubishi PLC, Taiwan Touch Screen

B. Omron Relay, Schneider Contactor

C. Control Panel with pictures.

2, Automatic Brick Making Machine of hydraulic system (Taiwan):

A. Proportional electro-hydraulic relief valves

B. Solenoid directional valves

C. Pressure control valves

D. Water cooling system

E. Hydraulic Tank with oil filter

3, Automatic Brick Making Machine of Table Vibration System, High frequency low amplitude

A. table vibration with HIGH FREQUENCY LOW AMPLITUDE

B. press head has three Oil Cylinders

C. vibration platform has fixed support bar and adjustable support bar

4, Automatic Brick Making Machine of Mould

A. use the 16# manganese steel

B. Line cutting machine to make sure 100% accurate size of mould

C. heat treatment can reach HRC 61

D. Based on the customer requirement to make the various moulds,

Like hollow block, solid block, interlock block, curbstone block etc.

5, AutomaticBrick Making Machine of Feeder

A. the fork is working about 40 degrees to push the material into the mould

B. it can feed the various materials to the various moulds
