- Place of Origin: China
- Brand Name: hengxing
- Model Number: HQTY3-25
block making machine brick making machine HQTY3-25
Advantages:
Save investment ,save place ,save energy
It is easy to maintain the machine ,easy operation
It can product all kinds of brick by exchanging moulds
for exampe make the various blocks ,like hollow block, solid brick.
porous block and paving brick etc
The feature of technology:
1, Table Vibration plus head press vibration system:
A: table vibration plus head press vibration
B: working stable and safely
C: head press has three oil cylinders
D: improve the block of density and intensity
2, control system:
A. Mitsubishi PLC, self diagnosed for Trouble shooting
B. touch screen controller (Eview,Shenzhen), easy operation
C. International electrical components: Omron, Schneider
3, Proportional electro-hydraulic relief valves (Taiwan,Calyca)
A. Its working steady with low noise
B. Hi-precision
C. easy micro-adjusting
4, 360 degrees of seconds’ pendulum feeding system:
A, feeding motor is working with two or four transmission shafts
B, it can feed various materials to the various moulds
C, improve the block of density and intensity
D, improve the feeding speed within 2 seconds
E, it is very easy to clean the feeder.
5, American and British combination of sealing system
A, it is connected 100% closely, no leaking at all,
B, to make sure the hydraulic system working stable and smooth
6, heat treatment for the mould
A, use the 16# manganese steel,
B, heat treatment can reach HRC 61
C, Working 150,000times
7, Pallets feeder of pusher brake system
A, big size pusher brake for the different type of pallets
B, feeding the pallets smooth, no stop
8, water cooling system
A, keep the hydraulic oil of working temperature
B, protect the hydraulic system and mechanical system
- Place of Origin: China
- Brand Name: hengxing
- Model Number: HQTY3-25
block making machine brick making machine HQTY3-25
Technical Parameters :
Dimension of the host machine | 3000*1350*2620mm |
Host power | 18.3KW |
Moulding area | 400*600mm |
Vibration force | 30KN |
Moulding period | 15-25s |
Factory area | 450m² |
The size of the splint | 680*530*20mm |
Rated pressure of the machine | 16Mpa |
Weight of the host machine | 3T |
